20 Gallon - Traditional
SKU 20TRS
$750.00
Ship Time Is 30 Days Or Less
Standard or E
lectric
Standard
Electric
1 item in the bag
Quantity:
1
Add More
Go to Checkout
P
roduct Details
Stillz 20-Gallon Copper Distillation System – Traditonal Style
Experience professional-level performance with the Stillz 20-Gallon Distillation System, engineered for makers who want consistent, high-quality results and great for distilled water applications. Built from premium copper and equipped with precision temperature control, this system delivers excellent heat distribution, smooth operation, and long-lasting durability.
Whether you’re scaling up your workflow or upgrading from a smaller still, the 20-gallon model offers the ideal balance of capacity, efficiency, and craftsmanship.
CAPACITY & SPECS
20-Gallon Copper Pot
Heavy-duty 20-gallon copper pot with Pasco temperature gauge for accurate heat monitoring
Height: 38″
Diameter: 15″
Line Arm Length: 19″
Total Setup Length: 45″
Designed for even heat distribution and efficient distillation performance
3-Gallon Thumper
Durable 3-gallon copper thumper enhances vapor refinement for cleaner, more consistent output
Includes a 1 1/2″ brass flush-out for easy draining and maintenance
Built with a 12″ long, 1/2″ copper cross pipe and union fittings for secure and accessible connections
3-Gallon Condensing Worm
Equipped with 9 ft of copper condensing coil for superior cooling and smooth condensation
3/4″ inlet/outlet hose connections ensure reliable water flow
Efficient cooling design for stable, consistent operation
StillZ Electrical Heating System (Electric Units Only)
(1) 220V PID controller with precision temperature probes for automated, accurate heat control
(1) 5500W electrical heating element provides fast heat-up and steady performance
Ideal for users seeking a clean, controlled, and highly efficient electric heating solution
Need a Larger Thumper or Condensing Worm?
Upgrades Available – Call: 978-457-5366
Tell Steve Steven Stafford sent you out of Lamar And Springfield Missouri or click photo and go to their website.
Steven StillZ Whiskey
Recipes Steven StillZ Whiskey
Steven StillZ Whiskey
Ingredients:
10 lbs Whole Kernel Corn, untreated
5 Gallons Water
1 Cup Yeast
Champagne Yeast Starter
Directions:
Put corn in a burlap bag and wet with warm water.
Place bag in a warm dark place and keep moist for about ten days.
When the sprouts are about a 1⁄4” long, the corn is ready for the next step.
Wash the corn in a tub of water, rubbing the sprouts and roots off.
Throw the sprouts and roots away and transfer the corn into your primary fermenter.
With a pole or another hard object, mash the corn. (Make sure the kernels are cracked.)
Next add 5 gallons of boiling water and when the mash cools, add yeast. Seal fermenter and vent with water sealed vent.
Fermentation will take 7-10 days. When fermentation is done, pour into still, filtering through a pillow case to remove all solids.
Call Us Any Time
(978) 457-5366
Address
50 Bridge St. Nashua N.H. 03060
I love my 6 gallon still it makes a couple bottles 750 ml of good moonshine and a third bottle with distilled water in it. It would take a lot of donation money for me to part with it.
Sincerely
S. M. Stafford
Cooling Worm Pump Adapters
SKU PA10
$65.00
New Product
Add to your existing cooling worm for use with our pump!
1 item in the bag (19 more available)
Quantity:
1
Add More
Go to Checkout
Product Details
These Garden Hose Pump Adapters will allow you to attach our pump system to your existing cooling worm.
If you already have one of our stills and are sick of wasting water these will allow you to upgrade to our Cooling worm pump.
Contents- 1 Male Adapter and 1- Female Adapter
Cooling Worm Circulating Pump
SKU PMP10
$145.00
New Pro
duct!
Add to Your Still Order!
1 item in the bag (9 more available)
Quantity:
1
Add More
Go to Checkout
Product Details
Add this Circulating Pump to your order and pump directly for a cooler or other container.
When added to your order we substitute the garden hose fittings with Pump Compatible Fittings.
No wasting water. This is a Diaphragm Pump with an Amperage Controller, the higher the Amperage the faster the water flows.
110 Volt 15 Amp Circut required.
Custom Propane Burner
SKU BRN20
$395
m in the bag
Quantity:
1
Add More
Go to Checkout
Product Details
Propane Burner 220,000 BTU Propane Gas Burner For 20 Gallon Still.
More than enough heat to fire our 10, 20, 30, 40 and 50 Gallon Moonshine Stills. Super Accurate Adjustment Dial Makes for Precise Temperature Adjustments.
Super reinforced to handle the weight of your still with a full load of mash.
Quickly Bring Your Wash to Strike Temperature and Better Utilize Your Time
When Ordering Please Let Us Know What Size Still You Have.
Everyone needs a drink with. Trump being president of USA
North Georgia Still Company
20 Gallon Distillers Kit
CAPACITY:
20 Gallon Still
5 Gallon Thumper
5 Gallon Worm
STILL:
Made with 20 oz/22 gauge copper
18.5” diameter x 35” tall
3/4” threaded ball valve drain
Temperature gauge
Tri clamp cap (6" diameter)
1-3/8” OD (1-1/4" ID) lyne arm
Temperature gauge, vacuum pressure relief valve & fast-acting pressure relief valve in cap
THUMPER:
11.5" diameter x 12" tall
Made with 20 oz/22 gauge copper
4” fruit port
1/2" threaded ball valve drain
Temperature gauge
1-3/8" OD (1-1/4" ID) thumper input
7/8" OD (3/4" ID) thumper output
WORM:
11.5" diameter x 12" tall
Made with 20 oz/22 gauge copper
15 ft 5/8" OD (1/2" ID) worm coil
Built in 3/4" threaded garden hose fittings for water ports
Valve on bottom threaded port
Barbed fittings on top and bottom threaded water ports
OTHER SPECS:
Completely piped tri clamp ferrules
Thumper output tapers down to 5/8" OD (1/2" ID) worm coil
3 thermometers
Submersible water pump
10 ft clear vinyl tubing
EXPECTED OUTPUT
ABV (alcohol by volume) of mash between 10% to 20% = 2-4 gallons
WHAT MAKES AN NGSC STILL
The massive vapor cones allow excellent head space. 6-inch diameter Tri Clamp Cap alleviates the need for traditional flour paste. It is the largest TCC in the industry installed on hobby stills. The opening in the collar of the still is large enough to give easy access to your still pot for cleaning. The top of the collar is rolled over to give you a nice smooth edge, promote safety against cuts and add strength. Bodies have beads rolled into them, allowing for a robust, & beautiful still. A ½ inch NTP thermometer port is installed center mass of the still body, cap, and thumper. This allows you to get an accurate reading of your wash and vapor temperature with your thermometer installed. Bottoms are designed to hold the weight of your wash. With double thick bottom seams, our stills can support over double the weight you will load them with.
The worm condenser comes standard with water inlets and outlets to cycle cold water in the can, which allows your shine to cool down more efficiently. The worm coil has 15-foot of 5/8 OD copper tubing that is braced on the sides for added support. It is designed to be used with a hose, or a water pump. The top of the worm is rolled over to give you a nice smooth edge, promote safety against cuts and add strength.
The thumper’s inlet runs all the way to the bottom. It is then cut at a 45-degree angle, with flutes cut into it to maximize effectiveness. The outlet barely protrudes into the top of the thump keg, allowing the vapors to escape with ease, keeping pressure to a minimum. 4 Inch fruit port on top makes it easy to add fruit or other ingredients in the thumper to infuse flavors into your shine. 1/2 NTP thermometer port allows you to add your thermometer to accurately read the vapors in the thumper.
All tubing is deburred and chamfered to allow your fittings to connect without hassle.
The still and thumper have ball valve drain ports installed for easy drainage after your run.
Something often overlooked: the seams! We put thick, beautiful seams on all of our equipment. Our solder work is what you expect in a high quality still.
Attention:
Do not use this product before reading and understanding the instructions. Your instructions will be under the first set of flaps as you open your still. (Refer to set-up video for a visual). You can also find a copy of these instructions and all other resources by clicking on the Resources tab. If you cannot find the instructions, or do not understand them, contact us immediately.
Improper use can cause injuries to the operator and damage to your equipment. Improper use may void any or all manufacturer warranties.
Electric systems can take 4-6 weeks to ship depending on stock availability and are ordered when we start building the still
-FREE SHIPPING-
Regular price$2,037.00Sale price
Add 32 Oz/18 Gauge Copper Upgrade to 20 Gallon Distillers Kit?-- Choose Add 32 Oz/18 Gauge Copper Upgrade to 20 Gallon Distillers Kit? --Yes: add $441.00
Upgrade Still Bottom to 48 Oz/16 Gauge (1/16") Copper?-- Choose Upgrade Still Bottom to 48 Oz/16 Gauge (1/16") Copper? --Yes: add $173.00
Add Worm/Condenser Connection Pipe? useful for stripping runs, or anytime you want to distill without the thumper-- Choose Add Worm/Condenser Connection Pipe? --Yes: add $88.00
Add Fill Port on Vapor Cone?-- Choose Add Fill Port on Vapor Cone? --Add 3" Fill Port w/ End Cap: add $105.00Add 3" Fill Port w/ Sight Glass: add $200.00Add 4" Fill Port w/ End Cap: add $131.00Add 4" Fill Port w/ Sight Glass: add $252.00Add 6" Fill Port w/ End Cap: add $179.00Add 6" Fill Port w/ Sight Glass: add $347.00
Add Clean Out Port to Still? Secondary access port near the bottom of your still pot. Allows easier access to the inside of your still bottom for cleaning and maintenance.-- Choose Add Clean Out Port to Still? --4" Clean Out Port: add $131.006" Clean Out Port: add $179.00
Upgrade 4" End Cap to Sight Glass on Thumper?-- Choose Upgrade 4" End Cap to Sight Glass on Thumper? --Yes: add $121.00
Add Temperature Gauge in Worm?-- Choose Add Temperature Gauge in Worm? --Yes: add $53.00
Upgrade to Sealed Worm with 4" Access Port?-- Choose Upgrade to Sealed Worm with 4" Access Port? --Yes: add $137.00
Add Copper Proofing Parrot?-- Choose Add Copper Proofing Parrot? --Proofing Parrot: add $100.00Max Flow Proofing Parrot: add $131.00Adjustable Proofing Parrot: add $210.00Adjustable Proofing Parrot w/ Tri Clamp Connections: add $263.00
Add Propane Burner? 200,000 BTU High Pressure Low Profile Burner. Runs off propane.-- Choose Add Propane Burner? --Add Propane Burner?: add $150.00
Add Electric Heating System? Make your still electric. Comes with controller and heating element. Uses tri clamp to plug into the pot. Includes a stainless end cap so the port can be plugged. 120V is a dual element system and requires 2 separate 20 amp circuits. One element will plug into the control box and the other will plug into the wall unless the second control box option is chosen. Heat up times: 110V - Approximately 1.5 hours --- 220V - Approximately 1 hour (Requires 30 amp breaker). ALL OPTIONS INCLUDE END CAP, CLAMP & GASKET TO SEAL OFF WHEN NOT IN USE-- Choose Add Electric Heating System? --Add 220V 5500W Electric System: add $677.00Add 120v 4000w Electric Heating System: add $730.00Add Electric PORT ONLY x1: add $32.00Add Electric PORT ONLY x2: add $63.00
Is this a gift? Add this bundle to give to your loved ones! Please email customercare@ngstillco.com if it is a special occasion for a personalized card! Gift bundle will include an NGSC hat, koozie, moonshine mix (1 cup sample - random), sticker & a card showing what was ordered!-- Choose Is this a gift? Add this bundle to give to your loved ones! Please email customercare@ngstillco.com if it is a special occasion for a personalized card! --YES PLEASE!: add $57.00
